where should the oil dipstick be located on a dodge 270 hemi


Mopar Muscle
Item Posts    Sort Order

where should the oil dipstick be located on a dodge 270 hemi


macaroo macaroo
New User | Posts: 5 | Joined: 03/11
Posted: 03/21/11
07:58 PM

where should the oil dipstick be located on a dodge 270 hemi? a little help

Budnicks Budnicks
Guru | Posts: 1497 | Joined: 08/10
Posted: 03/22/11
03:13 PM

macaroo 1st off welcome to the MMM forum. I have a book from Mopar Performance "Hemi Engines" p4876824 that shows on page 96, the dipstick on the 331ci on the driverside rear of the engine & looks like it's behind the cylinder head in the block kind of inline with the intake bolts & close to the distributor. I don't know if the 1951-56 331ci are at all interchangable I don't think they are the 270 Hemi was a 1 year engine in Dodges only & 1955 Dodge 270ci Hemi not shown in any illistrations in any of my books. I'm not an early Hemi expert by any meens, I would do a Google search for illistrations on the 1955 270ci Dodge Hemi. There is a sorce for parts in the book "Hemi Engine" author L.S.Shepard,    Egge Parts House, Sante Fe Springs Ca. 1-800-866-5440,    Automotive Innovations Unlimited, Orange Ca. 1-714-639-7625,    Hyatt Engineering, Milpitas Ca. 1-408-946-2007,     Performance Automotive Wharehouse, Chatsworth Ca. 1-818-678-3203 (I don't know if the #'s are still good the book was published in 1998) That gives you some referances to start with all supplied info for the book so they may beable to shed some lite on the situation for you. Good luck.    Budnicks
"Fill Your Library Before You Fill Your Garage" Good Luck  "Budnicks"

tuffnuff tuffnuff
Moderator | Posts: 324 | Joined: 03/11
Posted: 03/22/11
08:38 PM

Welcome to the forum Macaroo, I found a passenger side pic of a 1955 270 Hemi and there is no dipstick to be seen.,. so I would assume it's on the D/S.
The pics may be copyrighted, but I will send them to you, in a PM (Private Message)
Found one that's OK for posting here.

55Hemi

Smile
When The Flag Drops.,.

tuffnuff

The Bull ***t Stops.,.
tuffnuff

P. Engineer, Engine Builder

Budnicks Budnicks
Guru | Posts: 1497 | Joined: 08/10
Posted: 03/22/11
09:28 PM

Thanks Tuff I was looking & cant find anything photo wise.   Budnicks
"Fill Your Library Before You Fill Your Garage" Good Luck  "Budnicks"

tuffnuff tuffnuff
Moderator | Posts: 324 | Joined: 03/11
Posted: 03/22/11
10:01 PM

I sent 3 pics his way, plus one here, and even though the pics are all of the 1955 270 Hemi and as clear as a bell, the dipstick is not to be found on either side, I'm stumped.
I'll send you the pics in a PM, mebbe you can spot something I missed.

Smile
When The Flag Drops.,.

tuffnuff

The Bull ***t Stops.,.
tuffnuff

P. Engineer, Engine Builder

Ron1973 Ron1973
Enthusiast | Posts: 379 | Joined: 09/10
Posted: 03/22/11
11:10 PM

I found one from a 1955, thats supposed to be the 270. I didn't take the time to upload it to put in here, its all rusted up but it shows it on the drivers side on the intake side of the head. It to is copy written and macaroo me to-also welcome to MM.. Ron...

http://www.thehemi.com/forums/viewtopic.php?f=11&t=3497
____________________
**
Ron1973

tuffnuff tuffnuff
Moderator | Posts: 324 | Joined: 03/11
Posted: 03/22/11
11:28 PM

OK, front on driver side

270Hemidipstick

Smile
When The Flag Drops.,.

tuffnuff

The Bull ***t Stops.,.
tuffnuff

P. Engineer, Engine Builder

Ron1973 Ron1973
Enthusiast | Posts: 379 | Joined: 09/10
Posted: 03/22/11
11:45 PM

Thanks tuffnuff... I would have uploaded it if asked but ill bet the time for me to do it, well thanks .. hope it helps.
____________________
**
Ron1973

tuffnuff tuffnuff
Moderator | Posts: 324 | Joined: 03/11
Posted: 03/23/11
06:45 AM

No biggie at all Ron, I resized the pic and it only took a minute to post.,. a pic is worth 1000 words.

Smile
When The Flag Drops.,.

tuffnuff

The Bull ***t Stops.,.
tuffnuff

P. Engineer, Engine Builder

Ron1973 Ron1973
Enthusiast | Posts: 379 | Joined: 09/10
Posted: 03/23/11
12:45 PM

Thanks just the same, i can re-size, but dial-up slow whatever way. its a good photo, bad shape (engine) but it should help with identification. good luck to you macaroo.
____________________
**
Ron1973

marcohotrod340 marcohotrod340
Enthusiast | Posts: 470 | Joined: 09/08
Posted: 03/23/11
02:47 PM

awesome photo. smallblocks have the dipstick in the front

Budnicks Budnicks
Guru | Posts: 1497 | Joined: 08/10
Posted: 03/23/11
11:18 PM

Thanks tuff I looked for a while couldn't find I guess the drawing I have in the Hemi book is not the same I thought it was a 331ci or 354ci hemi but it could have been a 270ci hemi I wasn't sure. Front drvr. side, dose it go thru the block or straight into the pan?   Budnicks
"Fill Your Library Before You Fill Your Garage" Good Luck  "Budnicks"

macaroo macaroo
New User | Posts: 5 | Joined: 03/11
Posted: 03/24/11
06:55 PM

I'll have to show some picture of mine can't find it anywhere might not be a 270

macaroo macaroo
New User | Posts: 5 | Joined: 03/11
Posted: 03/24/11
07:09 PM

Thanks Budnicks

Ron1973 Ron1973
Enthusiast | Posts: 379 | Joined: 09/10
Posted: 03/24/11
08:20 PM

Post a picture macaroo and maybe we can help you identify what ya have.. Do these photos here even come close to what you have? Ron
____________________
**
Ron1973
